Cardholder Data PCI DSS: What to Know

Cardholder Data PCI DSS: What to Know

Most security leaders know their organization handles cardholder data. Fewer have confirmed exactly where it lives, which systems are in scope as a result, and whether their current scope documentation would hold up under QSA validation.

Cardholder data PCI DSS compliance begins with scope. The most expensive scoping mistakes rarely come from the systems organizations deliberately include. They come from the account data flows that were never mapped, which expose organizations to breach risk, and the systems swept in without cause, which may inflate assessment costs. This piece covers how PCI DSS scope is defined under v4.0.1, where account data commonly hides, what proper scope documentation requires under Requirement 12.5.2, and what getting it wrong costs in both directions.

What Cardholder Data Means Under PCI DSS

The PCI SSC Glossary defines account data as the parent category covering two subsets:

Cardholder data (CHD) — at minimum, the full PAN. May also include cardholder name, expiration date, and/or service code when stored or transmitted with the PAN.

Sensitive authentication data (SAD) — full track data (magnetic-stripe or chip equivalent), card verification codes (CAV2/CVC2/CVN2/CVV2/CID), and PINs/PIN blocks.

The distinction matters because each carries different obligations under PCI DSS v4.0.1:

  • PAN must be rendered unreadable wherever it is stored (Req. 3.5.1)
  • Other CHD elements (name, expiration date, service code) may be stored without that obligation, but fall under PCI DSS controls when present with the PAN or in the CDE
  • SAD must not be stored after authorization, even if encrypted — with a narrow exception for issuers and companies supporting issuing services with a legitimate, documented business need (Req. 3.3.3)

What triggers scope: Where PAN is stored, processed, or transmitted, a cardholder data environment (CDE) exists. Scope follows account data more broadly; however, systems that handle SAD are in scope even where no PAN is present. Per PCI DSS v4.0.1 Section 4, scope covers:

  • System components, people, and processes that store, process, or transmit CHD and/or SAD
  • Components with unrestricted connectivity to those systems
  • Any component that could impact the security of cardholder data and/or sensitive authentication data

Account Data Elements Under PCI DSS v4.0.1

Element

Type

May Be Stored After Authorization?

Protection When Stored

Protection When Transmitted

Primary Account Number (PAN)

CHD

Yes, kept to a minimum

Must be rendered unreadable (Req. 3.5.1)

Strong cryptography over open, public networks (Req. 4.2.1)

Cardholder Name

CHD

Yes, when present with PAN

Protect per applicable requirements

Protected via encrypted channel when transmitted with PAN

Expiration Date

CHD

Yes, when present with PAN

Protect per applicable requirements

Protected via encrypted channel when transmitted with PAN

Service Code

CHD

Yes, when present with PAN

Protect per applicable requirements

Protected via encrypted channel when transmitted with PAN

Full Track Data

SAD

No (Req. 3.3.1.1)¹

Protect with strong cryptography if held pre-authorization (Req. 3.3.2)

Not governed by Req. 4; transmitted during authorization

CAV2 / CVC2 / CVN2 / CVV2 / CID

SAD

No (Req. 3.3.1.2)¹

Protect with strong cryptography if held pre-authorization (Req. 3.3.2)

Not governed by Req. 4; transmitted during authorization

PINs / PIN Blocks

SAD

No (Req. 3.3.1.3)¹

Protect with strong cryptography if held pre-authorization (Req. 3.3.2)

Governed by PCI PIN Security Requirements, not PCI DSS Req. 4

¹ Issuers and companies supporting issuing services may retain SAD where there is a legitimate, documented business need (Req. 3.3.3).

Cardholder name, expiration date, and service code do not need to be rendered unreadable, even when stored alongside the PAN. PCI DSS v4.0.1 requires only the PAN to be rendered unreadable wherever it is stored. Once these elements are stored with the PAN or otherwise reside in the cardholder data environment, however, they fall in scope and must be protected under the PCI DSS controls applicable to cardholder data. This includes network security controls, access controls, logging, and vulnerability management, all of which expand your attack surface.

Unencrypted PAN is the element organizations most often store without realizing it. Full track data and card verification codes show up far less frequently but are the most dangerous when they do, since they can never be retained after authorization. All three commonly surface in application and error logs, databases, and legacy transaction records.

How PCI DSS Scope Is Determined

PCI DSS v4.0.1 applies to the system components, people, and processes that store, process, or transmit account data, plus anything that could impact the security of that data. PCI SSC scoping guidance sorts these into three commonly used groups: systems in the cardholder data environment (CDE), connected-to or security-impacting systems, and out-of-scope systems. The first two are in scope; the third is not. For in-scope components, the specific requirements that apply depend on each component's function and location. Both CDE and connected-to systems are evaluated against all requirements to determine which ones are applicable.

Category 1: CDE systems

System components, people, and processes that store, process, or transmit CHD and/or SAD, plus system components on the same network segment (for example, the same subnet or VLAN) or with unrestricted connectivity to them. These systems are evaluated against all PCI DSS requirements to determine which apply. This is the core of nearly every assessment.

Category 2: Connected-to and/or Security-Impacting Systems

System components that can connect to or access the CDE, directly or through another system such as a jump server, or that could impact the security of cardholder data and/or sensitive authentication data even without a direct connection. Like CDE systems, these are in scope and must be evaluated against all PCI DSS requirements to determine which apply to each. They must not provide an access path between the CDE and out-of-scope systems.

Examples include Active Directory servers providing authentication to CDE systems, SIEM platforms monitoring CDE logs, patch management servers updating CDE components, and administrator jump servers used to access the CDE.

Category 3: Out-of-scope systems

System components, people, and processes that are completely isolated from the CDE, with no connectivity, no shared network segment, and no ability to impact the security of cardholder data and/or sensitive authentication data. PCI DSS controls do not apply to these components, but the entity must still confirm and document that they genuinely qualify.

Reaching out-of-scope status requires two conditions:

  • No connectivity or access to the CDE
  • No security impact on the CDE, even indirectly

If network segmentation is used to achieve this:

  • It must be purpose-built (separate network segments alone are not sufficient)
  • It must be confirmed by the assessor
  • It must be penetration-tested at least every 12 months; every 6 months for service providers (Requirements 11.4.5 and 11.4.6)

Network segmentation is not a PCI DSS requirement, but it is the main technical tool for keeping on-premises systems out of scope. Other routes eliminate the CDE entirely rather than segmenting around it:

  • Fully outsourcing payment processing to a PCI DSS-compliant third party
  • Using a PCI-listed P2PE solution
  • Removing card-data flows through tokenization or hosted payment pages

Diagram and scope documentation requirements:

Requirement 1.2.3 requires an accurate network diagram showing all connections between the CDE and other networks, including wireless. Requirement 1.2.4 requires an accurate data-flow diagram showing all account data flows. Both must be updated as needed upon changes to the environment. Requirement 12.5.2 requires entities to confirm PCI DSS scope (including updating data-flow diagrams per Requirement 1.2.4) at least once every 12 months and upon significant change. Service providers must do so at least every six months under Requirement 12.5.2.1.

Where Account Data Hides and Why It Matters

The most consequential scoping errors are usually not the ones where organizations openly argue a system should be out of scope. They are the ones where account data has silently migrated into systems that were never mapped, and so never checked.

Common Hidden Account Data Locations

Location

How Account Data Gets There

Scoping Consequence

Web server and application logs

PANs passed in URLs or query strings, or debug logging capturing full transaction payloads in legacy integrations or poorly configured payment pages

The web server, log management platform, and any connected archival storage are CDE systems and enter scope. Audit-log review (Req. 10.4, at least daily for CDE components, with automated mechanisms required after March 31, 2025) and retention (Req. 10.5, at least 12 months, with the most recent three months immediately available) apply. Cleartext PAN in logs also violates Req. 3.5.1 and must trigger incident-response procedures under Req. 12.10.7.

Unencrypted backups

Database or system backups that include PAN-containing tables without applying the same rendering-unreadable controls as the live database

Backup media, backup management systems, and storage destinations enter scope. PAN in backups must be rendered unreadable under Req. 3.5.1. The security of offline backup media locations must be reviewed at least every 12 months under Req. 9.4.1.2.

Emailed chargeback files

Acquiring banks or processors send chargeback dispute files containing full PANs to finance or operations teams via standard email

The email platform, recipients' workstations, and any shared drives where files are saved enter scope, often entirely outside the existing compliance program. Transmitting unprotected PAN via email also implicates Req. 4.2.1 (strong cryptography required for PAN in transit over open, public networks) and Req. 4.2.2 (PAN must not be sent via end-user messaging technologies unless adequately protected).

Development and test environments

Real cardholder data used for testing because it is more convenient than generating synthetic records. Debug logging in these environments can also capture full transaction payloads including SAD.

Pre-production environments using live PANs must be included in the CDE and protected in accordance with all applicable PCI DSS requirements, or live PANs must be removed (Req. 6.5.5). Test data and accounts must be removed before production (Req. 6.5.6). Where SAD is present, storage is prohibited after authorization (Req. 3.3.1) regardless of encryption. These environments typically lack the monitoring and patching cadence of production.

Spreadsheets and shared drives

Finance or operations staff extract PANs into spreadsheets for reconciliation or reporting and save them to shared drives or personal devices

Every system on which those files reside enters scope. PAN must be rendered unreadable (Req. 3.5.1, via encryption, truncation, hashing, or tokenization). Access controls and data-retention limits apply. Discovery of PAN in these unauthorized locations should trigger incident-response procedures under Req. 12.10.7.

Voice recordings and IVR systems

Pause-and-resume recording failures or absent DTMF masking cause call recordings to capture full PANs or card verification codes spoken or keyed by customers during phone-based transactions

Telephony platforms, call recording systems, and any storage repositories for recordings enter scope. SAD captured in recordings violates Req. 3.3.1 post-authorization and Req. 3.5.1. DTMF masking or channel separation is the recognized mitigation.

Paper and hard-copy records

Printed reports, receipts, or manual card imprints retained beyond their useful life or disposed of without proper destruction

Physical media containing account data enters scope under Req. 9.4, which governs the protection and secure destruction of media. Unsecured paper records routinely fall outside physical access controls applied to digital systems.

Improper PCI DSS scoping, whether through over-scoping the environment or missing hidden account-data flows, increases compliance complexity, cost, and the risk of failed validation. The 2025 Verizon Data Breach Investigations Report found that third-party involvement appeared in 30% of analyzed breaches, a doubling from 15% the prior year. Separately, IBM's 2024 Cost of a Data Breach Report found that 35% of breaches involved data stored in unmanaged data sources, or "shadow data," the same uncontrolled stores that sit outside formal compliance programs and outside the scope of PCI DSS controls.

The Cost of Getting Scope Wrong

Scoping errors carry costs in both directions.

Over-scoping inflates cost and effort

Over-scoping happens when systems end up in scope that could legitimately be excluded. Common causes:

  • Flat networks with no segmentation, which can pull hundreds of systems into scope even though only a handful actually store, process, or transmit account data
  • Missing tokenization controls that would otherwise isolate PAN-handling systems
  • Self-hosted payment forms that could be replaced with a fully outsourced alternative

Scope reduction is one of the most impactful cost levers available. Options include validated network segmentation (confirmed by penetration testing under Requirements 11.4.5 and 11.4.6), tokenization, hosted payment pages, and validated P2PE solutions.

For e-commerce merchants specifically, the SAQ pathway reflects scope directly:

Scenario

Likely SAQ

Scale of obligation

Self-hosted payment form

SAQ D

All applicable PCI DSS requirements

Merchant page delivers any part of the payment form

SAQ A-EP

Significantly more than SAQ A

Fully outsourced via redirect or compliant iframe

SAQ A

Limited to outsourced-processing requirements

SAQ eligibility always depends on implementation specifics and payment channel. Confirm with your QSA before assuming a particular pathway applies.

Under-scoping creates breach exposure

Where over-scoping wastes budget, under-scoping is the more dangerous error. When system components that store, process, or transmit account data are left out of the entity's PCI DSS scope, they remain in scope by definition but lack the required controls in practice. They are not monitored, patched, or access-reviewed at the frequency PCI DSS requires. In a breach, these overlooked systems are a common entry point precisely because no one was watching them.

What PCI DSS v4.0.1 Requires Under Requirement 12.5.2

Requirement 12.5.2 requires entities to document and confirm PCI DSS scope at least once every 12 months and upon significant change to the in-scope environment. The core obligation was effective immediately for v4.0 assessments. The seven detailed scoping-validation elements became fully assessable after March 31, 2025. Service providers must confirm scope at least every six months under Requirement 12.5.2.1, which was future-dated to March 31, 2025.

What makes this requirement different

The scoping confirmation must be the entity's own documented internal exercise, separate from whatever scope validation the QSA performs during a formal assessment. It cannot be satisfied by pointing to the QSA's work in the annual ROC.

The seven required elements

#

What the entity must document

1

All data flows across payment stages (authorization, capture, settlement, chargebacks, refunds) and acceptance channels (card-present, card-not-present, e-commerce)

2

Updated data-flow diagrams per Requirement 1.2.4

3

All locations where account data is stored, processed, and transmitted, including locations outside the CDE, applications that process CHD, system-to-system transmissions, and file backups

4

All system components in the CDE, connected to the CDE, or that could impact CDE security

5

All segmentation controls in use, the environments they isolate, and documented justification for any environments considered out of scope

6

All third-party connections with access to the CDE

7

Confirmation that all of the above are accurately reflected in the defined scope

What we commonly see in first-cycle v4.0.1 assessments

Four gaps appear frequently:

  • Scoping exercises completed but not documented
  • Data-flow diagrams not updated after new integrations (Requirement 1.2.4)
  • System component inventories not reconciled against what the network actually contains (Requirement 12.5.1)
  • No documented review of segmentation controls, and no penetration testing to confirm they still effectively isolate the CDE (Requirements 11.4.5 and 11.4.6)

Knowing Exactly What Is in Scope Is Where Cardholder Data PCI DSS Compliance Starts

Scoping is not a box to check before the real cardholder data PCI DSS compliance work begins. It is the work. Requirement 12.5.2 requires organizations to document and confirm scope at least annually, against seven specific elements, as a separate exercise from whatever their QSA performs during formal assessment.

Securisea provides advisory services to help organizations define, document, and optimize their PCI DSS scope before and between formal assessments. Because Securisea maintains separation of duties between its advisory and assessment teams, organizations that engage Securisea for scope advisory work with a separate, independent QSA team for formal validation.

Contact Securisea to schedule a scope review or learn more about our PCI DSS validation and advisory services.
